SPECIFICATIONS
ITEM CONDITIONS UNIT NOMINAL LIMIT
1 Video Output 75 ohm load Vpp 1.0
2 Optical Digital Out dBm -18
3 Audio(PCM)
3-1. Output Level 1kHz 0dB Vrms 2.0
3-2. S/N dB 110
3-3. Freq. Response
DVD fs=48kHz 20~22kHz dB ± 2
CD fs=44.1kHz 20~20 kHz dB ± 2
3-4. THD+N 1 kHz 0dB % 0.005
NOTES:
1. All Items are measured without pre-emphasis unless otherwise specified.
2. Power supply : AC120 V 60 Hz
3. Load imp. : 100 K ohm
4. Room ambient : +25 °C
1-1-1 E5500SP
