Mitsubishi DD-4021 - Electrical Parts List

20010719 1-15-1 E5542EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
 have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTE:
Tolerance of Capacitors and Resistors are noted with
the following symbols.
Main CBA
AV CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DVD MAIN CBA N79M0EUP
Ref. No. Description Part No.
AV CBA
Consists of the following:
0VSA11636
CAPACITORS
C1001  METALLIZED FILM CAP. 0.01µF/250V K or CT2E103DC011
 METALLIZED FILM CAP. 0.01µF/250V M CT2E103MS037
C1002 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C1003 ELECTROLYTIC CAP. 2.2µF/250V M or CA2E2R2S6009
ELECTROLYTIC CAP. 2.2µF/250V M(105ºC) CE2EMASTH2R2
C1004 ELECTROLYTIC CAP. 100µF/200V M CE2DMZNDL101
C1005 CERAMIC CAP. B K 120pF/500V CCD2JKP0B121
C1006  SAFETY CAP. 2200pF/250V or CCG2EMA0F222
 SAFETY CAP. 2200pF/125V or CCG2BMA0E222
 SAFETY CAP. 2200pF/250V CCG2EMA0E222
C1007 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1012 ELECTROLYTIC CAP. 1000µF/16V M CE1CMASDL102
C1013 FILM CAP.(P) 0.0033µF/50V J or CMA1JJS00332
FILM CAP.(P) 0.0033µF/50V J CA1J332MS029
C1014 ELECTROLYTIC CAP. 1000µF/10V M CE1AMASDL102
C1015 ELECTROLYTIC CAP. 220µF/10V M CE1AMASDL221
C1016 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1018 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C1021 CERAMIC CAP. B K 0.01µF/50V CCD1JKS0B103
C1022 CERAMIC CAP.(AX) X K 5600pF/16V CCA1CKT0X562
C1024 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1025 CHIP CERAMIC CAP. B K 0.1µF/25V or CHD1EK30B104
CHIP CERAMIC CAP. B K 0.1µF/16V CHD1CK30B104
C1026 CHIP CERAMIC CAP. B K 0.1µF/25V or CHD1EK30B104
CHIP CERAMIC CAP. B K 0.1µF/16V CHD1CK30B104
C1029 CERAMIC CAP.(AX) X K 5600pF/16V CCA1CKT0X562
C1030 ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASDL221
C1031 FILM CAP.(P) 0.01µF/50V J or CMA1JJS00103
FILM CAP.(P) 0.01µF/50V J CA1J103MS029
C1032 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1033 CERAMIC CAP. YV Z 0.022µF/50V or CCD1JZSYV223
CERAMIC CAP. F Z 0.022µF/50V CCD1JZS0F223
C1034 ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASDL221
C1035 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1201 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1202 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1203 CHIP CERAMIC CAP. CH J 680pF/50V CHD1JJ3CH681
C1204 CHIP CERAMIC CAP. CH J 680pF/50V CHD1JJ3CH681
C1205 CHIP CERAMIC CAP. CH J 390pF/50V CHD1JJ3CH391
C1206 CHIP CERAMIC CAP. CH J 390pF/50V CHD1JJ3CH391
C1207 CHIP CERAMIC CAP. CH D 9pF/50V CHD1JD3CH9R0
C1208 CHIP CERAMIC CAP. CH D 9pF/50V CHD1JD3CH9R0
C1221 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1222 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1245 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V CHD1EZ30F104
C1246 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V CHD1EZ30F104
C1247 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1249 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1353 CHIP CERAMIC CAP. B K 0.1µF/25V or CHD1EK30B104
CHIP CERAMIC CAP. B K 0.1µF/16V CHD1CK30B104
C1354 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJ3CH101
C1356 ELECTROLYTIC CAP. 47µF/6.3V M CE0KMASDL470
C1401 ELECTROLYTIC CAP. 33µF/6.3V M CE0KMASDL330
C1402 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V CHD1EZ30F104
C1403 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1405 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1421 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V CHD1EZ30F104
C1423 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1441 ELECTROLYTIC CAP. 33µF/6.3V M CE0KMASDL330
C1443 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1447 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1461 ELECTROLYTIC CAP. 33µF/6.3V M CE0KMASDL330
C1463 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1481 ELECTROLYTIC CAP. 33µF/6.3V M CE0KMASDL330
C1483 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C2002 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C2003 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V CHD1EZ30F104
C2004 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C2007 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V CHD1EZ30F104
C2011 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V CHD1EZ30F104
C2012 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V CHD1EZ30F104
CONNECTORS
CN1001 FMN CONNECTOR, TOP 24P 24FMN-BTRK JCFNG24JG002
CN1601 FMN CONNECTOR, TOP 18P 18FMN-BTK JCFNG18JG001
CN2001 CONNECTOR BASE, 6P TUC-P06P-B1 J3TUA06TG001
DIODES
D1001 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 ND8Z001N4005
D1002 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 ND8Z001N4005
Ref. No. Description Part No.
