Mitsubishi DD-4021 - Page 45

20010719 1-15-6 E5542EL
Function CBA
CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2037 CARBON RES. 1/6W J 10 Ω or RCX6JATZ0100
CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R2054 CHIP RES.(1608) 1/16W 0 Ω or RRXGZR5Z0000
CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2059 CHIP RES.(1608) 1/16W 0 Ω or RRXGZR5Z0000
CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
SWITCHES
SW2008 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B SST0101HH013
MISCELLANEOUS
AC1001

AC CORD WAC0172LTE01 or WAC0172LTE01
 AC CORD LA-2145 or WAC0172LW005
 AC CORD 9806190 WAC0172AS004
CR1001

GAP. FNR-G3.10D FAZ000LD6005
F0001 CABLE ASSY(BLACK) AWG22 UL1007 L=35MM WX3001A2FF04
F1001  FUSE 1A/250V or PAGA20CW3102
 FUSE 1A/250V PAGG20CAG102
FL2002 F.I.P. 25U39170SAN TVFD1C0FT037
JK1201 RCA JACK MSP-253V1-07 PBSN JXRL030LY030
JK1202 RCA JACK MSP-244V10-42 PBSN JXRL040LY031
JK1401 S TYPE JACK MDC-050V-2.4 JXEL040LY001
RM2001 REMOTE RECEIVER PIC-37042LU USESJRSKK033
SA1001  SURGE ABSORBER CNR-10D471K or NVQZR10D471K
 SURGE ABSORBER JVR-10N471K or NVQZR10N471K
 SURGE ABSORBER ENC471D-10AC QVQZC471D10A
T1001  PULSE TRANS SA-00718R LTT00CPSA094
W1001 24P FFC POWER TO MAIN WX1E5500-006
W1601 18P FFC POWER TO MAIN WX1E5500-008
WJ1001 4P P-WIRE ASSEMBLY WX1E5520-001
Ref. No. Description Part No.
FUNCTION CBA
Consists of the following:
0VSA11639
CONNECTOR
CN2003 CONNECTOR, 6P TUC-P06X-B1 JCTUS06TG001
SWITCHES
SW2031 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B SST0101HH013
SW2032 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B SST0101HH013
SW2033 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B SST0101HH013
SW2034 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B SST0101HH013
SW2036 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B SST0101HH013
SW2037 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B SST0101HH013
Ref. No. Description Part No.
