Mitsubishi F9Q2

F9QENGINE-
CylinderHead
11A-11-1
11.CYLINDERHEAD
REMOVALANDINSTALLATION
30Nm
+
50
_
±
4
_
®
Fullyloosen
®
25Nm
+
213
_
±
7
_
2
3
4
1
8
5
6
7
9
10
11
REN0185
12
Removalsteps
"
E
A
1.Cylinderheadbolt
"
D
A
2.Cylinderheadgasket
3.Tappet
A
A
""
C
A
4.Retainerlocks
5.Valvespringretainer
A
A
""
C
A
6.Valvespring
7.Valvespringseat
8.Intakevalve
9.Exhaustvalve
A
B
""
B
A
10.Valvestemseal
A
C
""
A
A
11.Valveguide
12.Cylinderhead
PWEE0001
E
Jun.2000MitsubishiMotorsCorporation
