2-2
COOLING SYSTEM
Structure
Hose layout
S4Q2 engine
K21, K25
engines
S4S engine
Lower hose
Shroud
Radiator
Upper hose
S4Q2,
S4S
Reservoir tank
K21, K25
209611
Fan (directly coupled to engine)
209610
