3-3
ELECTRICAL SYSTEM
Structure
Console box
1Water temperature gauge
2 Fuel gauge
3Various warning lights
4 Instrument panel
5 Starter switch
6 Lighting switch, turn signal switch
7Forward-reverse lever
1
6
5
34
2
7
209622
