Seat and restraint systems
2-19
2
Adjustable seat belt shoulder anchor (front seats)
N00406300328
The seat belt anchor height can be adjusted. To move the
anchor, pull the lock knob (A) and slide the anchor to the
desired position. Release the lock knob to lock the anchor into
position.
● Do not install any accessory or sticker that makes
the light difficult to see.
WARNING
!
