Features and controls
3-69
3
Energy level gauge
N00572800024
The energy level gauge indicates the remaining power in the
main drive lithium-ion battery during charging or when the
electric motor switch is in the “ON” position.
OTE
● The charging indicator is also illuminated during charg-
ing.
Refer to “Charging indicator” on page 3-72.
Low energy warning indicator
N00572900025
When the electric motor switch is in the “ON” position and the
remaining bar of the energy level gauge shows 2 bars or less,
the warning indicator (A) and the charging bars (B) flash as
follows:
When the energy level gauge shows 2 bars: The warning indi-
cator flashes.
When the energy level gauge shows 1 bar: The warning indica-
tor and the charging bars flash alternately.
Recharge the main drive lithium-ion battery as soon as possi-
ble.
F- Battery is fully charged.
E- Charge the battery.
