*: Fusible link
● Some fuses may not be installed on your vehicle, depend-
ing on the vehicle model or specifications.
● The table above shows the main equipment corresponding
to each fuse.
No. Symbol Electrical system Capacity
1 Tail light (left) 7.5 A
2
Cigarette lighter/
12 V power outlet
15 A
3 — — —
4Starter 7.5 A
5 Audio amplifier 20 A
6— — —
7 Tail light (right) 7.5 A
8 Outside rearview mirrors 7.5 A
9
Control unit
(Electric motor unit)
7.5 A
10 Control unit 7.5 A
11 Rear fog light 10 A
12 Door lock 15 A
13 Interior lights (Dome lights) 10 A
14 Rear window wiper 15 A
15 Gauges 7.5 A
16 Relay 7.5 A
17 Heated seat 20 A
18 Option 10 A
19
Heated door outside rearview
mirrors
7.5 A
20 Windshield wiper 20 A
21 Back-up lights 7.5 A
22 Defogger 30 A
23 Heater 30 A
24 12V starter battery 30 A*
25 Radio 10 A
26 Electronic controlled unit 15 A
27 — Electronic controlled unit 7.5 A
