71
MECHANICAL STRUCTURE
Follow the reverse procedure of removal and disassembly for assembly and installation of front axle.
Shim "K"
Calking
Front bracket
Liner
4T-32205
4T-30205
"J"
H
Grease
Grease
Rear bracket
Bond
Pinish shaft
Grease
Grease
Grease
Liner "B"
Bond
6010
Liner "A"
Grease
Grease
Liner "F"
Packing
Liner
6304UU
6206
"G"
14T
18T
Liner "C"
Liner "G"
Liner "E"
Liner "D"
mm {in}
12T
Packing
Grease
32T
TMB304
6306
6305
51106
Grease
GZ3W26-020
11 0.05 {0.433 0.002}
3 0.05 {0.12 0.002}
25 0.05 {0.98 0.002}
17.9 0.05 {0.705 0.002}
A
D
B
C
6-2 ASSEMBLY AND INSTALLATION OF FRONT AXLE
