MECHANICAL STRUCTURE
A
A
B
B
D
11 0.05mm {0.433 0.002 in}
0.05 to 0.2mm {0.002 to 0.008 in}
17.9 0.05mm {0.705 0.002in}
C
25 0.05mm {0.98 0.002in}
3 0.05mm {0.12 0.002in}
0 to 0.2mm {0 to 0.008 in}
Liner "G"
Liner "D"
Liner "E"
Liner "G"
Liner "F"
Liner "C"
