75
MECHANICAL STRUCTURE
(Unit: mm {in})
9 Assembly of Knuckle Arm
1. Adjust the clearance "F" between the knuckle arm and holder to be within 0.05 to 0.20mm {0.002 to 0.008in}
with the thrust liner "F".
2. Apply the lithium grease to the bush for the knuckle arm.
(Unit: mm {in})
Item Thickness Usable Limit
Liner "E"
0.10 {0.004} 1135 3016 000
0.40 {0.016} 0731 0002 504
0.80 {0.031} 0731 0002 508
1.00 {0.039} 0731 0002 510
1.20 {0.047} 0731 0002 512
Item Thickness Usable Limit
Thrust
Liner "F"
0.80 {0.031} 1438 1319 600
1.00 {0.039} 1438 1319 500
1.20 {0.047} 1438 1319 400
1.40 {0.055} 1438 1319 300
Toe in functions as an important role to control the
stability of the vehicle. Tendency for control loss of
vehicle while running may be caused by misalignment of
toe in. In such case, inspect and adjust.
(Unit: mm {in})
1) Loosen the locknut for tie rod end.
2) Remove the nut for tie rod end from the knuckle
arm.
3) Adjust the length of tie rod end by turning only
the tie rod end.
4) Tighten the locknut after adjusting.
4ORQUETO.sM[TO
KGFsCMTOLBFsFT]
Item Referential Value
Toe In (A - B) 0 to 10.0 {0 to 0.39}
$GMXVWWKHERWKVLGHVRIWLHURGHQGDWWKHVDPH
WLPH
0DNHVXUHWKHQRQH[LVWHQFHRIORRVHQHVVIRU
IURQWWLUHZKLOHDGMXVWLQJ
B
)RUZDUG
A
GS7W3-195
7LHURGHQG&
.QXFNOHDUP
/RFN1XW
,QVSHFWLRQDQG0DLQWHQDQFH
7RH,Q
