Mitsubishi MELSEC-A A1SCPUC24-R2 - Notes on Installing the Base Unit

29
4.1.3 Notes on installing the base unit
Take ease of operation, ease of maintenance, and environmental
durability into consideration when you are installing the programmable
controller on the panel.
(1) Mounting dimension
Mounting dimensions of each base unit are as follows:
Dimensions: mm (inch)
A1S32B A1S33B A1S35B A1S38B
A1S52B
(S1)
A1S55B
(S1)
A1S58B
(S1)
A1S65B
(S1)
A1S68B
(S1)
W
220
(8.66)
255
(10.04)
325
(12.80)
430
(16.93)
155
(6.10)
260
(10.24)
365
(14.37)
315
(12.40)
420
(16.54)
Ws
200
(7.87)
235
(9.25)
305
(12.01)
410
(16.14)
135
(5.31)
240
(9.45)
345
(13.58)
295
(11.61)
400
(15.75)
H 130 (5.12)
Hs 110 (4.33)
H
Hs
W
Ws
