Mitsubishi MELSEC-A A1SCPUC24-R2 User Manual

70
For all modules, the insulation system is photocoupler insulation and the output
indications are LED indications.
*1 The dynamic scan cycle is 13.3ms (FAST mode) or 106.7ms (SLOW mode).
(Set using the DIP switch on the module rear.)
*2 Set using the DIP switch on the module front.
Model Type
No. of
Points
Rated
Load
Voltage
Max. Load Current
Max. Output
Response Time
Point Common Module
OFF to
ON
ON to
OFF
A1SY80
Transistor
Output
(source type)
16
12/24V
DC
0.8A 3.2A -
2ms or
lower
2ms or
lower
A1SY81
32
0.1A 2A -
A1SY
81EP
0.1A
(25°C),
0.05A
(55°C)
2A
(25°C)
1.6A
(55°C)
-
0.5ms
or
lower
1.5ms
or
lower
A1SY82 64 0.1A 1.6A -
2ms or
lower
2ms or
lower
A1S42Y
Transistor
Output
(dynamic)
16/32
48/64
*2
0.1A
(40°C)
0.05A
(55°C)
--
2ms or
lower
*1
2ms or
lower
*1
