7 - 4
MEMORY CASSETTE AND BATTERY7.
(2) Removal of the memory cassette
(a) While pressing the top and bottom projections for hook disengagement with
fingers, pull the memory cassette.
A2SNMCA
-30KE
CPU module
A2SNMCA
-30KE
CPU module
Projections for hook
disengagement
