Connection to SYSMAC C Series 5.
5-1
5. Connection to SYSMAC C Series
The GOT can be connected to the SYSMAC C Series manufactured by OMRON via a host link
unit as shown below.
• Applicable PLC units and host link units
< SYSMAC C Series >
A host link unit or a CPU equipped with an interface for host link is required.
For the setting of the host link unit, refer to the F940GOT Operation Manual offered
separately.
• System configuration
RS232C RS422
RS232C
RS422
To host link unit
F940GOT-SWD-E/LWD-E
To Next Page
