5. PARAMETERS
5 - 30
Control
mode
No./symbol/
name
Setting
digit
Function
Initial
value
[unit]
P S T
Set the command notch filter.
_ _ x x Command notch filter setting frequency selection
Refer to table 5.6 for the relation of setting values to frequency.
00h
PB45
CNHF
Command
notch filter
_ x _ _ Notch depth selection
Refer to table 5.7 for details.
0h
x _ _ _ For manufacturer setting 0h
Table 5.6 Command notch filter setting frequency selection
Setting
value
Frequency [Hz]
Setting
value
Frequency [Hz]
Setting
value
Frequency [Hz]
00 Disabled 20 70 40 17.6
01 2250 21 66 41 16.5
02 1125 22 62 42 15.6
03 750 23 59 43 14.8
04 562 24 56 44 14.1
05 450 25 53 45 13.4
06 375 26 51 46 12.8
07 321 27 48 47 12.2
08 281 28 46 48 11.7
09 250 29 45 49 11.3
0A 225 2A 43 4A 10.8
0B 204 2B 41 4B 10.4
0C 187 2C 40 4C 10
0D 173 2D 38 4D 9.7
0E 160 2E 37 4E 9.4
0F 150 2F 36 4F 9.1
10 140 30 35.2 50 8.8
11 132 31 33.1 51 8.3
12 125 32 31.3 52 7.8
13 118 33 29.6 53 7.4
14 112 34 28.1 54 7.0
15 107 35 26.8 55 6.7
16 102 36 25.6 56 6.4
17 97 37 24.5 57 6.1
18 93 38 23.4 58 5.9
19 90 39 22.5 59 5.6
1A 86 3A 21.6 5A 5.4
1B 83 3B 20.8 5B 5.2
1C 80 3C 20.1 5C 5.0
1D 77 3D 19.4 5D 4.9
1E 75 3E 18.8 5E 4.7
1F 72 3F 18.2 5F 4.5
Table 5.7 Notch depth selection
Setting
value
Depth [dB]
Setting
value
Depth [dB]
0 -40.0 8 -6.0
1 -24.1 9 -5.0
2 -18.1 A -4.1
3 -14.5 B -3.3
4 -12.0 C -2.5
5 -10.1 D -1.8
6 -8.5 E -1.2
7 -7.2 F -0.6
