Mitsubishi MR-JE-70A User Manual

11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 2
11.1.1 Combinations of cable/connector sets
Refer to "HG-KN/HG-SN Servo Motor Instruction Manual" for options for
servo motor power supply, electromagnetic brake, and encoder.
(Note)
Personal computer
5)
1) (Packed with the
servo amplifier)
To 24 V DC power supply
for electromagnetic brake
Servo motor
Encoder
connector
Servo amplifier
Operation
panel
Controller
3)
2)
4)
CN3
CN1
CN2
Power
connector
Brake
connector
CNP1
Note. Connectors for 1 kW or less. Refer to section 3.3.3 (1) (b) for 2 kW or more.
