Mitsubishi PUG24AYB - Capacity Correction Factors

036-21534-001 Rev. B (0703)
Mitsubishi Electronics 2003 25
MODEL
Refrigerant piping length (one way)
25 ft 40 ft 55 ft 70 ft
PUG18AYB 1.0 0.982 0.966 0.947
PUG24AYB 1.0 0.976 0.951 0.926
PUG30AYB 1.0 0.988 0.976 0.964
PUG36AYB 1.0 0.983 0.964 0.946
PUG42AYB 1.0 0.991 0.982 0.973
CAPACITY CORRECTION FACTORS FOR VARIOUS PIPE LENGTHS9
