Mitsubishi PUG30AYB User Manual

036-21534-001 Rev. B (0703)
Mitsubishi Electronics 2003 19
PC42+PUG42 (Indoor Air = 1100 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 41,552 11.01 3,774 23,327 29,502 34,488 39,474 45,649 63 202
65 42,515 11.21 3,793 20,606 26,780 31,939 37,098 43,272 64 203
67 43,479 11.41 3,811 17,884 24,059 29,390 34,721 40,895 65 204
69 44,442 11.61 3,828 15,163 21,338 26,841 32,344 38,519 66 205
71 45,405 11.81 3,845 12,442 18,616 24,292 29,967 36,142 67 206
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 40,516 10.04 4,035 23,184 29,359 34,122 38,885 45,060 67 233
65 41,490 10.23 4,056 20,396 26,571 31,585 36,600 42,774 69 234
67 42,489 10.39 4,089 17,609 23,783 29,049 34,315 40,489 71 235
69 43,437 10.61 4,094 14,821 20,996 26,513 32,030 38,204 71 236
71 44,410 10.80 4,113 12,034 18,208 23,976 29,745 35,919 72 238
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 39,480 9.19 4,296 23,041 29,215 33,755 38,296 44,470 71 264
65 40,464 9.37 4,318 20,187 26,361 31,232 36,102 42,277 72 265
67 41,500 9.50 4,368 17,333 23,508 28,708 33,909 40,083 74 267
69 42,431 9.73 4,361 14,479 20,654 26,185 31,716 37,890 75 268
71 43,415 9.91 4,381 11,626 17,800 23,661 29,522 35,697 76 269
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 36,925 8.11 4,551 21,837 28,012 32,258 36,504 42,679 74 299
65 38,040 8.30 4,584 19,174 25,349 29,980 34,610 40,785 75 300
67 39,181 8.46 4,629 16,512 22,686 27,701 32,716 38,891 77 302
69 40,270 8.67 4,644 13,849 20,024 25,423 30,822 36,997 79 303
71 41,385 8.86 4,672 11,187 17,361 23,145 28,929 35,103 81 305
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 34,369 7.15 4,807 20,633 26,808 30,760 34,713 40,887 76 334
65 35,615 7.35 4,849 18,162 24,336 28,727 33,118 39,293 78 336
67 36,862 7.54 4,889 15,691 21,865 26,694 31,524 37,698 81 337
69 38,108 7.74 4,927 13,219 19,394 24,661 29,929 36,104 83 339
71 39,354 7.93 4,963 10,748 16,922 22,629 28,335 34,509 85 340
PERFORMANCE DATA - OPERATING PRESSURES
4
