PK-FK INDOOR UNITS WITH PUG OUTDOOR UNITS
MODELS PK18FK PK24FK PK30FK PK36FK
Item Unit Cooling Cooling Cooling Cooling
Electrical Circuit
Voltage V 208/230 208/230 208/230 208/230
Frequency Hz 60 60 60 60
Total Input kW 1.82 2.38 2.85 3.34
Indoor Fan Current A 0.8 0.8 0.9 1.0
Booster Heater Current A -- -- -- --
Outdoor Fan Current (FLA) A 0.5 0.5 0.5 1.4
Compressor Current (230v) A 7.3 9.6 12.6 14.0
Refrigerant Circuit
Condensing Pressure PSIG 260 271 287 278
Suction Pressure PSIG 85 86 84 77
Discharge Temperature °F 182 191 196 191
Condensing Temperature °F 107 112 109 112
Suction Temperature °F 62 58 61 59
Refrigerant Pipe Length FT. 25 25 25 25
Refrigerant Charge - 3 lbs 8 oz 3 lbs 6 oz 4 lbs 3 oz 3 lbs 15 oz
Indoor Side
Intake Air Temperature
DB °F 80 80 80 80
WB °F 67 67 67 67
Discharge Air Temperature
DB °F 60 58 58 58
WB °F 59 57 56 56
Fan Speed RPM. 1490 1490 1490 1490
Airflow (High) CFM 710 710 990 990
Outdoor Side
Intake Air Temperature
DB °F 95 95 95 95
WB °F -- -- -- --
Fan Speed RPM. 1050 1050 1050 1100
Airflow (High) CFM 1690 1785 1600 2340
Capacity BTU/H 19400 23400 29200 34200
SHF -- 0.770.710.690.65
STANDARD OPERATING DATA
