Mitsubishi PUG30AYB User Manual

036-21534-001 Rev. B (0703)
32 Mitsubishi Electronics 2003
MODELS 36 AND 42
ITEM DESCRIPTION PUG36AYB PUG42AYB
1
Fan Guard (18”)
Fan Guard (22”)
026-35511-018
---
---
026-35511-022
2 Wireway 028-13215-000 028-13216-000
3 Fan Motor 024-26020-000 024-27596-000
4
Fan Blade 18” Diameter
Fan Blade 22” Diameter
026-34092-000
---
---
026-34593-000
5 Top 2218-1021/A 2260-1021/A
6 Outdoor Coil Assembly 373-19800-002 373-19800-004
7 Compressor
015-03560-001
(H29B33UABCA)
015-02092-005
(H23A423ABCA)
<
8 Compressor Mount (Pkg. of 4)
Compressor Mount (4 Req’d)
9435-1081
---
9435-1081
---
9
Dual Capacitor (45/5 MFD)
Dual Capacitor (35/5 MFD)
024-25895-000
---
---
024-25859-000
10 Contactor (30 amp) 024-27531-000 024-27531-000
11 Base Valve 3/4” 022-09049-750 022-09049-750
12
Base Valve 1/2” (.071 orifice)
Base Valve 1/2” (.080 orifice)
022-09047-005
---
---
022-09047-006
<
13 Filter Drier 029-22156-000 029-22157-000
14 Base Pan 2218-1011 2260-1011
15 Control Box Cover 2218-1151/A 2218-1151/A
16 Ground Lug 025-21798-000 025-21798-000
17 Coil Guard 026-35414-000 026-35416-000
18 Blockoff Panel 2236-1081/B 2248-1081/B
19 6 Position Plug 025-33306-006 025-33306-006
20 Plastic Mesh, Coil Guard 028-14726-000 028-14728-000
21 Kit, Motor Mounting (Acorn Nut) 363-90117-700 363-90117-700
22* Wiring Diagram 035-15861-501 035-15861-501
23* Harness, Compressor 025-31883-000 025-31884-000
24 Hubcap 026-39292-000 026-39292-000
25 High Pressure Switch 025-33305-048 025-33305-048
26 Low Pressure Switch 025-38610-000 025-38610-000
27 Accumulator Tank 026-34089-000 026-34090-000
28 Transformer 025-18452-000 025-18452-000
29 Control Board 031-01976-000 031-01976-000
30 Terminal Block 025-38589-002 025-38589-002
NOTE
:
*Not Shown
New replacement parts shown in bold face type at the first printing of parts list dated 4/
03.
Major components and suggested stocking items are shown with shaded item number.
“<“ Across from row indicates a change in that row.
--- Not applicable to specified model.
PARTS BREAKDOWN13
