Mitsubishi PUG30AYB User Manual

036-21534-001 Rev. B (0703)
6 Mitsubishi Electronics 2003
PC-GK INDOOR UNITS WITH PUG OUTDOOR UNITS
MODELS PC24GK PC30GK PC36GK PC42GK
Item Unit Cooling Cooling Cooling Cooling
Electrical Circuit
Voltage V 208/230 208/230 208/230 208/230
Frequency Hz 60 60 60 60
Total Input kW 2.38 2.85 3.34 4.35
Indoor Fan Current A 0.8 0.9 1.0 1.4
Booster Heater Current A -- -- -- --
Outdoor Fan Current (FLA) A 0.5 0.5 1.4 1.4
Compressor Current (230v) A 9.6 12.6 14.0 16.7
Refrigerant Circuit
Condensing Pressure PSIG 273 286 282 268
Suction Pressure PSIG 89 83 84 74
Discharge Temperature °F 191 196 190 191
Condensing Temperature °F 113 109 113 105
Suction Temperature °F 59 61 63 51
Refrigerant Pipe Length FT 25 25 25 25
Refrigerant Charge -- 4 lbs 9 oz 4 lbs 9 oz 5 lbs 0 oz 5 lbs 10 oz
Indoor Side
Intake Air Temperature
DB °F 80 80 80 80
WB °F 67 67 67 67
Discharge Air Temperature
DB °F 58 58 58 57
WB °F 56 57 57 56
Fan Speed RPM 1490 1490 1490 1490
Airflow (High) CFM 880 1240 1240 1240
Outdoor Side
Intake Air Temperature
DB °F 95 95 95 95
WB °F -- -- -- --
Fan Speed RPM 1050 1050 1100 1100
Airflow (High) CFM 1785 1835 2340 3320
Capacity BTU/H 24400 29800 36000 41500
SHF --0.750.780.720.71
STANDARD OPERATING DATA
3
