Mitsubishi PUG36AYB User Manual

036-21534-001 Rev. B (0703)
Mitsubishi Electronics 2003 3
* Conditions taken at ARI A (95° F outdoor / 80° F DB, 67° F WB indoor)
Based on ARI operating conditions. Specifications subject to change without notice.
* Conditions taken at ARI A (95° F outdoor / 80° F DB, 67° F WB indoor)
Based on ARI operating conditions. Specifications subject to change without notice.
* Conditions taken at ARI A (95° F outdoor / 80° F DB, 67° F WB indoor)
Based on ARI operating conditions. Specifications subject to change without notice.
PK SERIES - AIR CONDITIONING SYSTEMS
SYSTEM INDOOR OUTDOOR BTU/H* S.E.E.R. E.E.R.*
PKG18FK3 PK18FK3 PUG18AYB 19400 11.60 10.65
PKG24FK3 PK24FK3 PUG24AYB 23400 11.00 9.80
PKG30FK3 PK30FK3 PUG30AYB 29200 11.60 10.20
PKG36FK3 PK36FK3 PUG36AYB 34200 11.40 10.25
PC SERIES - AIR CONDITIONING SYSTEMS
SYSTEM INDOOR OUTDOOR BTU/H* S.E.E.R. E.E.R.*
PCG24GK PC24GK PUG24AYB 24400 10.50 9.35
PCG30GK PC30GK PUG30AYB 29800 11.00 9.65
PCG36GK PC36GK PUG36AYB 36000 11.20 10.05
PCG42GK PC42GK PUG42AYB 41500 10.00 9.50
PL SERIES - AIR CONDITIONING SYSTEMS
SYSTEM INDOOR OUTDOOR BTU/H* SEER. EER.*
PLG18AK PL18AK PUG18AYB 20000 11.40 10.50
PLG24AK PL24AK PUG24AYB 24000 10.00 9.00
PLG30AK PL30AK PUG30AYB 28400 10.30 9.30
PLG36AK PL36AK PUG36AYB 35600 11.00 9.90
PLG42AK PL42AK PUG42AYB 41000 10.00 9.25
ELECTRICAL SPECIFICATIONS - AIR CONDITIONING CONDENSING UNITS
MODEL PUG18AYB PUG24AYB PUG30AYB PUG36AYB PUG42AYB
Compressor
Locked Rotor Amps 54 57 73 82 129
Full Load Amps 9.6 12.1 14.7 16.0 20.0
Outdoor Fan Full Load Amps 0.5 0.5 0.5 1.4 1.4
Unit Total Full Load Amps 10.1 12.6 15.2 17.4 21.4
Max. Fuse Size (Amps) 20 25 30 35 45
Min. Circuit Ampacity 12.5 15.5 18.9 21.4 26.4
Max. Tubing Length 75 75 75 75 75
Max. Vertical Separation 50 50 50 50 50
SPECIFICATIONS
2
