036-21534-001 Rev. B (0703)
Mitsubishi Electronics 2003 31
MODELS 18, 24, AND 30
ITEM DESCRIPTION PUG18AYB PUG24AYB PUG30AYB
1 Fan Guard (18”) 026-35511-018 026-35511-018 026-35511-018
2 Wireway 028-13215-000 028-13215-000 028-13215-000
3 Fan Motor 024-26067-010 024-26067-010 024-26067-010
4 Fan Blade 18” Diameter 026-34091-000 026-34091-000 026-34091-000
5 Top 2218-1021/A 2218-1021/A 2218-1021/A
6 Outdoor Coil Assembly 373-19800-001 373-19800-001 373-19800-002
7 Compressor
015-03557-001
(H23B173ABCA)
015-03558-001
(H23B223ABCA
015-03559-001
(H23B28SABCA)
<
8 Compressor Mount (Pkg. of 4) 9435-1081 9435-1081 9435-1081
9
Dual Capacitor (25/5 MFD)
Dual Capacitor (30/5 MFD)
Dual Capacitor (35/5 MFD)
024-23997-000
---
---
---
024-24778-000
---
---
---
024-25859-000
10 Contactor 024-27531-000 024-27531-000 024-27531-000
11
Base Valve 5/8”
Base Valve 3/4”
022-09048-625
---
022-09048-625
---
---
022-09049-750
12
Base Valve 3/8” (.053 orifice)
Base Valve 3/8” (.059 orifice)
Base Valve 1/2” (.067 orifice)
022-09047-001
---
---
---
022-09047-002
---
---
---
022-09047-004
<
13 Filter Drier 029-22156-000 029-22156-000 029-22156-000
14 Base Pan 2218-1011 2218-1011 2218-1011
15 Control Box Cover 2218-1151/A 2218-1151/A 2218-1151/A
16 Ground Lug 025-21798-000 025-21798-000 025-21798-000
17 Coil Guard 026-35413-000 026-35413-000 026-35414-000
18 Blockoff Plate 2218-1081/B 2218-1081/B 2236-1081/B
19 6 Position Plug 025-33306-006 025-33306-006 025-33306-006
20 Plastic Mesh, Coil Guard 028-14725-000 028-14725-000 028-14726-000
21 Kit, Motor Mounting (Acorn Nuts) 363-90117-700 363-90117-700 363-90117-700
22* Wiring Diagram 035-18738-001 035-18738-001 035-18738-001
23* Harness, Compressor 025-31883-000 025-31883-000 025-31883-000
24 Hubcap 026-39292-000 026-39292-000 026-39292-000
25 High Pressure Switch 025-33305-048 025-33305-048 025-33305-048
26 Low Pressure Switch 025-38610-000 025-38610-000 025-38610-000
27 Accumulator Tank 026-34089-000 026-34089-000 026-34089-000
28 Transformer 025-18452-000 025-18452-000 025-18452-000
29 Control Board 031-01976-000 031-01976-000 031-01976-000
30 Terminal Block 025-38589-002 025-38589-002 025-38589-002
NOTE
:
*Not Shown
New replacement parts shown in bold face type at the first printing of parts list dated 4/
03.
Major components and suggested stocking items are shown with shaded item number.
“<“ Across from row indicates a change in that row.
--- Not applicable to specified model.
PARTS BREAKDOWN13
