9 - 28
9.1 PLC Parameters
9.1.2 High Performance model QCPU, Process CPU, Redundant CPU, Universal model QCPU
9
PARAMETERS
(11) X/Y assignment
Check the data set in the I/O assignment, Ethernet/CC IE/MELSECNET setting and
CC-Link setting.
Figure 9.22 X/Y assignment
Table9.23 X/Y assignment list
Item Parameter No. Description Setting range Default value Reference
X/Y assignment ----
The data set in the I/O
assignment, Ethernet/CC IE/
MELSECNET setting and CC-
Link setting can be checked.
---- ---- ----
To Next Page
