10
DEVICE EXPLANATION
10.2 Internal User Devices
10.2.4 Latch relay (L)
10 - 16
9
Parameters
10
Device Explanation
11
CPU Module Processing
Time
12
Procedure for Writing
Program to CPU ModuleAppendicesIndex
(4) Procedure for external outputs
Outputs (Y) are used to output sequence program operation results to an external
destination.
POINT
1. Internal relays (M) should be used when a latch (memory backup) is not
required.( Section 10.2.3)
2. For latch clear, the latch clear disabled range can be set to each device in the
device setting of the PLC parameter dialog box.( Section 6.3)
To Next Page
