App - 121
Appendix 5 Method of replacing High Performance model QCPU with Universal model QCPU
APPENDICES
(2) CPU modules that can configure a multiple CPU system with the
Universal model QCPU
CPU modules that can configure a multiple CPU system with the Universal model
QCPU are shown below.
(a) CPU modules that can configure a multiple CPU system with the Universal
model QCPU (except Q02UCPU)
(b) CPU modules that can configure a multiple CPU system with the Q02UCPU
TableApp.60 CPU modules that can comfiture a multiple CPU system with the Universal model QCPU (except Q02UCPU)
CPU module Model
Applicable version
Restrictions
Configured with
Q03UDCPU,
Q04UDHCPU or
Q06UDCPU
Configured with
Q13UDHCPU,
Q26UDCPU or Built-in
Ethernet port QCPU
Motion CPU
• Q172DCPU
• Q173DCPU
No restrictions No restrictions
Use the multiple CPU high-speed main
base unit (Q3 DB) for a main base
unit.
PC CPU module • PPC-CPU852(MS)
Driver S/W (PPC-DRV-02)
version 1.01 or later
Driver S/W (PPC-DRV-02)
version 1.02C or later
---
High Performance
model QCPU
• Q02CPU
• Q02HCPU
• Q06HCPU
• Q12HCPU
• Q25HCPU
Function version B or later Function version B or later ---
Process CPU
• Q02PHCPU
• Q06PHCPU
• Q12PHCPU
• Q25PHCPU
No restrictions No restrictions ---
TableApp.61 CPU modules that can configure a multiple CPU system with the Q02UCPU
CPU module Model Applicable version Restrictions
Motion CPU
• Q172CPUN(-T)
• Q173CPUN(-T)
• Q172HCPU(-T)
• Q173HCPU(-T)
No restrictions
The multiple CPU high-speed main base unit
(Q3 DB) cannot be used for a main base unit.
PC CPU module • PPC-CPU852(MS)
Driver S/W (PPC-DRV-02)
version 1.01 or later
---
