Appendix 1 Special Relay List
APPENDICES
*1: The module whose first 5 digits of serial No. is "06082" or later.
*2: The module whose first 5 digits of serial No. is "07012" or later.
*3: The module whose first 5 digits of serial No. is "07032" or later.
*4: This applies to the CPU module of function version B or later.
*5: The module whose first 5 digits of serial No. is "04012" or later.
*6: The module whose first 5 digits of serial No. is "05032" or later.
TableApp.8 Special relay
Number Name Meaning Explanation
Set by
(When Set)
Corres-
ponding
ACPU
M9
Corresponding
CPU
SM735
SFC comment readout
instruction in
execution flag
OFF : SFC comment readout
instruction is
inactivated.
ON : SFC comment readout
instruction is
activating.
• Turns on the instructions, (S(P).SFCSCOMR) to
read the SFC step comments and (S(P).
SFCTCOMR) to read the SFC transition condition
comments.
S (status change) New
Qn(H)
*2
QnPH
*3
QnPRH
*3
SM736
PKEY instruction
execution in progress
flag
OFF : Instruction not
executed
ON : Instruction execution
• ON when PKEY instruction is being executed.
Goes OFF when CR is input, or when input character
string reaches 32 characters.
S (Instruction
execution)
New
QnA
SM737
Keyboard input
reception flag for
PKEY instruction
OFF : Keyboard input
reception enabled
ON : Keyboard input
reception disabled
• Goes ON when keyboard input is being conducted.
Goes when keyboard input has been stored at the
CPU.
S (Instruction
execution)
New
SM738
MSG instruction
reception flag
OFF : Instruction not
executed
ON : Instruction execution
• Goes ON when MSG instruction is executed
S (Instruction
execution)
New
Qn(H)
QnPRH
QnA
SM774
PID bumpless
processing
(for complete
derivative)
OFF : Matched
ON : Not matched
• Specifies whether to match the set value (SV) with
the process value (PV) or not in the manual mode.
UNew
QnA
Q00J/Q00/Q01
*4
Qn(H)
QnPRH
QnU
SM775
Selection of refresh
processing during
COM instruction
execution
OFF : Performs link refresh
ON : Performs no link
refresh
• Select whether link refresh processing will be
performed or not when only communication with the
CPU module is made at the execution of the COM
instruction.
UNew
QnA
Q00J/Q00/Q01
Qn(H)
QnPH
OFF : Performs all refresh
processes
ON : Performs refresh set
by SD778
• Select whether to perform all refreshes or the refresh
processing set by SD778 when the COM instruction
is executed.
UNew
Q00J/Q00/Q01
*4
Qn(H)
*5
QnPH
*3
QnPRH
QnU
SM776
Enable/disable local
device at CALL
OFF : Local device disabled
ON : Local device enabled
• Set whether the local device of the subroutine
program called at execution of the CALL instruction
is valid or invalid.
UNew
QnA
Qn(H)
QnPH
QnPRH
QnU
SM777
Enable/disable local
device in interrupt
program
OFF : Local device disabled
ON : Local device enabled
• Set whether the local device at execution of the
interrupt program is valid or invalid.
UNew
SM780
CC-Link dedicated
instruction executable
OFF : CC-Link dedicated
instruction executable
ON : CC-Link dedicated
instruction not
executable
• Switches ON when the number of the CC-Link
dedicated instructions that can be executed
simultaneously reaches 32. Switches OFF when the
number goes below 32.
UNew QnA
SM794
PID bumpless
processing(for
incomplete derivative)
OFF : Matched
ON : Not matched
• Specifies whether to match the set value (SV) with
the process value (PV) or not in the manual mode.
UNew
Q00J/Q00/Q01
*4
Qn(H)
*6
QnPRH
QnU
