8
- 12
8.1 PLC Parameters
8.1.1 Basic model QCPU
8
PARAMETERS
(10) X/Y assignment
Check the data set in the I/O assignment, MELSECNET/Ethernet setting and CC-Link
setting.
Diagram 8.10 X/Y assignment
Table8.10 X/Y assignment list
Item Parameter No. Description Setting range Default value Reference
X/Y assignment ----
The data set in the I/O
assignment, MELSECNET/
Ethernet setting and CC-Link
setting can be checked.
---- ---- ----
