4.3 Installing Extension Base Units and Setting the Number of Stages
4
I/O NUMBER ASSIGNMENT
4.3 Installing Extension Base Units and Setting the Number of Stages
The extension base units shown in Table4.3 are available.
POINT
Extension base units cannot be connected to the slim type main base unit.
Table4.3 Available extension base units
CPU module Available extension base unit
Q00JCPU
Q5 B,Q6 B,Q6 RB
Q00CPU,Q01CPU
Q02CPU,Q02HCPU,Q06HCPU,Q12HCPU,Q25HCPU
Q5 B,Q6 B,Q6 RB, QA1S6 B
Q12PHCPU,Q25PHCPU
Q5 B,Q6 B,Q6 RB
Q12PRHCPU,Q25PRHCPU Not Available
