Mitsubishi Q02HCPU User Manual

10
DEVICE EXPLANATION
10.6 Index Register(Z) / Standard Device Resister(Z)
10.6.4 Switching scan/low speed exec. to Interrupt/fixed scan exec.
10 - 68
9
Parameters
10
Device Explanation
11
CPU Module Processing Time
12
Procedure for Writing Program to CPU ModuleAppendicesIndex
(3) Processing of file register block No.
(a) When switching from scan/low speed execution type program to interrupt/
fixed scan execution type program
The CPU module saves the file register block No. of the scan/low speed execution
type program and passes it to the interrupt/fixed scan execution type program.
(b) When switching from interrupt/fixed scan execution type program to scan/
low speed execution type program
The CPU module restores the saved file register block No.
Figure 10.65 File register block No. saving (protection)/restoration
[RSET K0]
Execution program
Block No. of file
register
Save area
Scan/low-speed
execution type
program
Switching Restored
Interrupt
program/fixed-cycle
execution type
program
Scan/low-speed
execution type
program
Block 1
Restored
Block 1Block 1Block 1 Block 1Block 0
Block 1
Transferred
Save
Block 1 0
