APPENDICES
Appendix 2 Special Register List
App
- 74
9
Device Explanation
10
CPU Module Processing
Time
11
Procedure for Writing
Program to CPU Module
Appendices
Index
TableApp.33 Special register
Number Name Meaning Explanation
Set by
(When set)
Corres-
ponding
ACPU
D9
Corresponding CPU
SD1589
Reason(s) for
system
switching failure
conditions
Reason(s) for
system switching
failure No.
Stores the reason(s) for system switching failure.
0: System switching normal (default)
1: Tracking cable is not connected , tracking cable error, FPGA circuit
failure.
2: H/W failure, power off, Reset, WDT error on the standby system
3: H/W failure, power off, Reset, WDT error on the Control system
4: Tracking data transfer initialization
5: Communication timeout
6: Serious error(except WDT error) on the Standby system
7: There is difference between both systems
(detected as Backup mode only)
8: During memory copy from control system to standby system
9: During online program change
10: During detection of intelligent function module failure on the standby
system
11: System switching being executed
Resets to "0" when host system is powered on.
Resets to "0" once system has been switched successfully.
S(when system
is switched)
QnPRH
SD1590
Switch request
network No.
Request origin
network No.
Stores the request origin at work No. when the SM1590 is turned on.
S (Error
occurrence)
New Q4AR
Network module
head address,
which requested
system
switching
Network module
head address,
which requested
system switching
Stores head address of network module which a system switch request
was initiated.
Turns off automatically by system, after network error is reset by user.
Please refer to SD1690 which stores the corresponding head address of
network module on other system.
S (Error
occurrence/Sta-
tus change)
New
QnPRH
SD1595
Memory copy
target I/O
Number
Memory copy
target I/O Number
Stores I/O No.(Standby system CPU module: 3D1
H
) of before SM1595
is set to on.
UNew
SD1596
Memory copy
status
Memory copy
status
Stores the execution result of Memory copy function.
0 : Memory copy successfully completed
4241
H
: Standby system power supply off
4242
H
: Tracking cable is disconnected or is damaged
4247
H
: Memory copy function is being executed
4248
H
: Unsupported memory copy destination I/O Number
S (Status
change)
New
b1 b0b15 b11to to
0
0/1
0/1 0
Module 0:
Module 1:
Module11:
SD1590
Each bit
0:OFF
1:ON
to
CPU module is invalid
as it is 2-slot model
Module on right side of
CPU module
Module at rightmost
end of 12-slot base
(Q312B)
