Appendix 3 List of Parameter No.
App - 98
9
Parameters
10
Device Explanation
11
CPU Module Processing Time
12
Procedure for Writing Program to CPU ModuleAppendicesIndex
(Continued on next page)
TableApp.39 List of parameter No.
Item Parameter No. Referance
Device points 2000H
Section 9.1.1(5),
Section 9.1.2(5),
Section 10.1,
Section 10.2
Latch (1) start/end 2001H
Section 3.7,
Section 6.3,
Section 9.1.1(5),
Section 9.1.2(5)
Latch (2) start/end 2002H
Local device start/end 2003H
Section 10.14.2,
Section 9.1.2(5)
WDT (watchdog timer)
setting
WDT setting
3000
H
Section 3.2,
Section 9.1.1(4),
Section 9.1.2(4)
Initial execution monitoring time
Section 3.3.1,
Section 9.1.2(4)
Low speed execution monitoring time
Section 3.3.3
Section 9.1.2(4)
Error check
Carry out battery check
3001H
Section 6.17,
Section 9.1.1(4),
Section 9.1.2(4)
Carry out fuse blown check
Verify module
Check device range at indexing
Diagnose redundant power supply system
Operating mode when
there is an error
Computation error
3002
H
Section 6.17,
Section 9.1.1(4),
Section 9.1.2(4)
Extended instruction error
Fuse blown
Module comparison error
Intelligent module program execution error
File access error
Memory card operation error
External power supply OFF
