1. SPECIFICATIONS
1.1 SPECIFICATIONS
Table 1.1 General specification
Item Specifications
Ambient operating
temperature
0 to 55 °C
Ambient storage
temperature
−20 to 75 °C
Ambient operating
humidity
10 to 90 % RH, No-condensing
Ambient storage
humidity
10 to 90 % RH, No-condensing
Frequency Acceleration Amplitude
No. of
sweeps
10 to 57Hz ⎯⎯
0.075mm
(0.003in.)
Under
intermitten
t vibration
57 to 150Hz 9.8m/s
2
⎯⎯
10 to 57Hz ⎯⎯
0.035mm
(0.001in.)
Vibration resistance
Conforming
to JIS B
3502, IEC
61131-2
Under
continuous
vibration
57 to 150Hz 4.9m/s
2
⎯⎯
10 times
each in
X, Y, Z
directions
(for 80min.)
Shock resistance
Conforming to JIS B 3502, IEC 61131-2
(147 m/s
2
, 3 times in each of 3 directions X Y Z)
Operating ambience No corrosive gases
Operating elevation *3 2000m (6562ft.) max.
Installation location Control panel
Over voltage category
*1
II max.
Pollution level *2 2 max.
Equipment category Class I
*1: This indicates the section of the power supply to which the equipment is assumed to be
connected between the public electrical power distribution network and the machinery within
premises. Category II applies to equipment for which electrical power is supplied from fixed
facilities. The surge voltage withstand level for up to the rated voltage of 300 V is 2500 V.
*2: This index indicates the degree to which conductive material is generated in terms of the
environment in which the equipment is used. Pollution level 2 is when only non-conductive
pollution occurs. A temporary conductivity caused by condensing must be expected
occasionally.
*3: Do not use or store the programmable controller in the environment when the pressure is
higher than the atmospheric pressure at sea level. Otherwise, malfunction may result. To use
the programmable controller in high-pressure environment, contact your nearest Mitsubishi
representative.
