42
Max. Response Time
Maximum
Simultaneous
Input Points
(Percentage
Simultaneously
ON)
OFF to ON ON to OFF
Field
Wiring
Points/
Common
Internal
Current
Consump-
tion
(5VDC)
NO. of
Occupied
Points
100%(110VAC)
60%(132VAC)
20ms or lower 35ms or lower
100%(110VAC) 20ms or lower 35ms or lower
60%(220VAC) 30ms or lower 55ms or lower
60%(220VAC) 30ms or lower 55ms or lower
25ms or lower 20ms or lower
75%(26.4VDC)
20ms or lower 20ms or lower
10ms or lower 10ms or lower
0.1ms or lower 0.2ms or lower
100%(26.4VDC)
10ms or lower 10ms or lower
Terminal 16 0.05A 16
10ms or lower 10ms or lower 0.08A
0.3ms or lower 0.3ms or lower 0.12A
60%(26.4VDC)
10ms or lower 10ms or lower
40-pin
connector
0.08A
32
10ms or lower 10ms or lower 0.09A
0.16A
50%(24VDC)
0.3ms or lower 0.3ms or lower
40-pin
connector
2
32
0.09A
64
100% 1.5ms or lower 3ms or lower
40-pin
connector
32 0.075A
*3
32
10ms or lower 10ms or lower
0.4ms or lower 0.5ms or lower
100%(26.4VDC)
10ms or lower 10ms or lower
Terminal 16 0.05A 16
60%(26.4VDC) 10ms or lower 10ms or lower
37-pin
D-sub
connector
32 0.08A 32
50%(26.4VDC) 0.3ms or lower 0.3ms or lower
40-pin
connector
32 0.16A 64
100%(26.4VDC) 0.4ms or lower
*1
0.4ms or lower
*1
24-pin
connector
- 0.08A
16/32/48/
64
For all modules, the insulation system is photocoupler insulation and the input indications are LED
indications.
*1................The dynamic scan cycle is 13.3ms.
*2................Set using the DIP switch on the module front.
*3 ..............0.08A is shown on the rating plate of the module.
