3
Model name
Item
Q62DAN Q64DAN Q68DAVN Q68DAIN
Insulation method
Between the I/O terminal and PLC power supply :
Between output channels :
Between external supply power and analog output :
Photocoupler isolation
No isolation
Transformer isolation
Dielectric withstand
voltage
Between the I/O terminal and PLC power supply :
Between external supply power and analog output :
500VAC for 1 minute
500VAC for 1 minute
Insulation resistance
Between the I/O terminal and PLC power supply :
Between external supply power and analog output :
500VDC 20M
or more
500VDC 20M
or more
I/O occupied points 16 points (I/O assignment: Intelligent 16 points)
Connected terminals 18-points terminal block
Applicable wire size 0.3 to 0.75 mm
2
Applicable solderless
terminal
R1.25-3
(A solderless terminal with sleeve
cannot be used)
FG terminal:
R1.25-3, 1.25-YS3, RAV1.25-3,
V1.25-YS3A
Other terminals than FG:
R1.25-3 (A solderless terminal
with sleeve cannot be used)
24 V DC + 20 %, – 15 %
Ripple, spike 500 mV P-P or less
Inrush current:
2.5 A,
within 250
s
Inrush current:
2.5 A,
within 260 s
Inrush current:
2.5 A,
within 230 s
Inrush current:
2.5 A,
within 230 s
External supply power
0.15 A 0.24 A 0.20 A 0.27 A
Internal current
consumption (5 V DC)
0.33 A 0.34 A 0.38 A 0.38 A
Weight 0.19 kg 0.20 kg 0.20 kg 0.20 kg
