Mitsubishi QX42 - Appendix 1.4 Spring Clamp Terminal Block

App - 10 App - 10
MELSEC-Q
APPENDICES
Appendix 1.4 Spring clamp terminal block
(1) Q6TE-18S(N) Installed on a module (Example: QX10)
Unit: mm
*1: The depth of the module installed with the Q6TE-18S(N) is equivalent with the factory default dimensions
for that module.
