Mitsubishi QX82

App - 7 App - 7
MELSEC-Q
APPENDICES
(2) 37-pin D-sub connectors
(a) A6CON1E soldering type 37-pin D sub-connector
(straight out type)
A6CON2E crimp-contact-type 37-pin D sub-connector
(straight out type)
Unit: mm
(b) A6CON3E pressure-displacement type 37-pin D-sub connector
(flat cable type)
Unit: mm
3.4
5.9
69.4
12.6
