Mitsubishi SRK 35ZS-W

-
31
-
'18 • SRK-T-250
Condition
Model SRK35ZS-W,WB,WT
N
oise Cooling 40 dB(A)
M
ODE
Level Heating 41 dB(A)
× Cooling ○ Heating
Model SRC35ZS-W
N
oise Cooling 50 dB(A)
L
evel Heating 48 dB(A)
× Cooling ○ Heating
ISO5151 T1/H1
10
20
30
40
50
60
70
10
20
30
40
50
60
70
63 125 250 500 1000 2000 4000 8000
63 125 250 500 1000 2000 4000 8000
Sound pressure level (dB)
(Standard 2x10
-5
Pa)
Mid octave band frequency (Hz)
Sound pressure level (dB)
(Standard 2x10
-5
Pa)
Mid octave band frequency (Hz)
Mike position: at highest noise level in position as mentioned below
Distance from front side 1m
Mike position
0.8m
1m
Unit
Mike position
(Center & low points)
N50
N30
N40
N60
N70
N20
N50
N30
N40
N60
N70
N20
10
20
30
40
50
60
70
10
20
30
40
50
60
70
Rated capacity value
（Indoor unit）
（Outdoor unit）
Model SRK35ZS-W, -WB, -WT
