Mitsubishi SRK19CES

-
160
-
Drain holes
286.4
12
50
290
49.6
43.5
850
203.1
510 136.9
476
Elogated hole
(2-12 x16)
314
12
328
Terminal block
Service valve (Liquid)
ø6.35 (1/4'')
Service valve (Gas)
ø15.88 (5/8'')
Ground
terminal
124
34.6
20˚
20˚
42.7
100.3
15
640
14
(b) Outdoor unit
Model SRC19CES
Model SRC25CES
Unit: mm
Terminal block
Service valve (Gas)
Flare fitting ø15.88 (5/8")
Service valve (Liquid)
Flare fitting ø6.35 (1/4")
25.1165.5
30°
30°
48.5103.3
750
24.1
Drain holes
2-ø15
25.8
29.8
87.9880
150580150
61
532
223
60
15
340
61 47.5
19 380 19
418
Unit: mm
