Mitsubishi SRK19CES

-
6
-
(b) Outdoor unit
Model SRC13ZEV-S
(4) Piping system
Model SRK13ZEV-S
Outdoor unitIndoor unit
Heat
exchanger
Room temp.
sensor
Humidity
sensor
Heat
exchanger
Heat
exchanger
Solenoid
valve
Flare connecting
Heat
exchanger
sensor
Piping
(Liquid)
ø6.35
Piping
(Gas)
ø9.52
Check joint
4 way valve
Service valve (Liquid)
Flare connecting
Discharge pipe
temp. sensor
Cooling cycle
Heating cycle
Outdoor air
temp. sensor
Heat exchanger
sensor
Compressor
uffler
M
Capillary tube Capillary tube
Strainer
Service valve
(Gas)
Electronic
expansion valve
14.4
595
96.5
42.5
35°
35°
90.6
29.7
340
13.5
312.5
14
17.5
164
286.4
290
45.4
49.6
463
62780
106 510
12
50
Drain holes
2-16 × 12
Ground
terminal
Terminal block
Service valve (Liquid)
Service valve (Gas)
Flare connection ø6.35 (1/4")
Flare connection ø9.52 (3/8")
Unit: mm
