Operation Manual Mitsubishi SS-Series diesel engines
Version 08/2004
ENGLISH
SPECIFICATIONS
3 SPECIFICATIONS
1
1 All specifications are subject to change without any prior notice.
System Item
Model
S4S S4S-DT S6S S6S-DT
ENGINE
PROPER
Type 4-cycle, water-cooled, vertical, overhead valve, diesel engine
Combustion chamber Swirl
chamber
type
Direct
injection
type
Swirl
chamber
type
Direct
injection
type
No. of cylinders 4 6
Bore x Stroke (mm) 94x120
Total displacement (l) 3.331 4.996
Compression ratio 22 17 22 17
Firing order 1 - 3 - 4 - 2 1 - 5 - 3 - 6 - 2 - 4
Dry weight (kg) 245 250 345 355
LUBRICATING
SYSTEM
Lubricating method Forced lubrication
Oil pump Trochoid pump
Oil filter Paper element type
Oil capacity:
FULL level/EMPTY level (l)
(Exclusive of oil filter capacity 0.5 l)
Shallow type oil pan: 9.0/6.0
Deep type oil pan: 9.0/6.0
Shallow type oil pan: 11.5/
9.0
Deep type oil pan: 14/11
FUEL SYSTEM
Fuel injection pump Bosch A or VE type
Nozzle Throttle type Hole type Throttle type Hole type
Fuel injection pressure 120 kgf/cm
2
180 kgf/cm
2
120 kgf/cm
2
180 kgf/cm
2
Fuel to be used Diesel fuel; see chapter 7
Governor Centrifugal weight type
INTAKE SYSTEM
Air cleaner Paper-element type
Turbocharger model Without TD04H Without TD06H
COOLING
SYSTEM
Cooling method Forced circulation of water
Water pump Centrifugal type
Coolant capacity (l)
(Engine proper only)
5.5 5.0 9.0 8.5
Table 1 Specifications
