– 37 –
No. Item Contents Care to be taken at the time of operation Anticipated defect Disposition (remarks)
7 How to load
into storage
1. Load by giving enough
space so as to be able to
secure circulation of
wing in the storage.
2. When loading and
unloading with door
open, stop the unit.
1. Dimensions shown below are specially
important.
The values in ( )are applicable for
TDJ430D.
1. It may happen that
temperature become
uneven at lower and
upper and front and rear
sides of storage.
2. When the storage door is
opened by circulating
wind, cold air in the
room will be replaced by
outside air, which makes
the storage temperature
rise.
1. Larger size load will
keep storage temperature
from becoming uneven.
2. Space between both sides
of a load is to be more
than 30mm.
To Next Page
