Mitsubishi TNW4EA Series User Manual

10
--
Mode Display
5
•
8
•
11
2
•
3
•
4
•
6
•
7
•
9
•
10
1
•
12
1
2
3
4
5
Buzzer setting display
Backlight setting display
Clock ON/OFF setting display
10
11
•
12
6
7
8
9
Centigrade / Fahrenheit setting display
(4) Set the user setting
Set the user setting display
Press the [MODE] switch (8 times, when the refrigeration unit is stopped, or 7 times when running) to change the display to the user settings display at the digital display area.
Setting the buzzer
Press the [UP] or [DOWN] switch to change the display to the buzzer setting display.
Setting the backlight
Press the [UP] or [DOWN] switch to display the backlight setting display. The digital display begins blinking, and the setting step display displays.
Press the [UP] or [DOWN] switch again to enable a
setting change operation (digital display begins blinking).
Press the [UP] switch for a "buzzer ON" setting, or the
[DOWN] switch for a "buzzer OFF" setting.
Press the [SET] switch to register the setting. The
display will change to then displays.
Light switch interlock
Always dim
ON only when panel is pressed (bright)
OFF
Always bright
The [UP] and [DOWN] switches can be used to select
the following setting items.
Setting the clock ON/OFF
Press the [SET] switch to register the setting. The display will change to clock ON/OFF setting display.
Press the [UP] or [DOWN] switch to start the digital display
blinking, and to change the display to the setting steps.
Press the [UP] switch to specify an ON setting, or the
[DOWN] switch to specify an OFF setting.
Press the [SET] switch to register the setting. The next
step (centigrade) then displays. After moving through the
steps, press the [MODE] switch to change the display to
the user settings display.
