Replacement of lamp bulbs
Maintenance 10-23
10
E01003404001
E01004004033
1. To create enough work space, turn the
steering wheel all the way in the direction
opposite to the side you wish to replace.
2. Remove the three clips (A), and then pull
back the splash shield (B).
3. While holding down the tab (C), pull out
the socket (D).
4. Turn the bulb (E) anticlockwise to remove
it.
5. To install the bulb, perform the removal
steps in reverse.
The following lamps use an LED instead of a
bulb.
If you need to repair or replace these lamps,
contact an authorised MITSUBISHI
MOTORS dealer.
• High mounted stop lamp
• Tail lamps
• Stop lamps
• Reversing lamps
• Licence plate lamps
Inside
1- Room lamp (front): 8 W
2- Room lamp (rear): 8 W
Front fog lamps (halogen bulb)*
*: Front of the vehicle
*: Front of the vehicle
