Instruments
Instruments and controls 5-7
5
Type 2
1-LED headlamp warning display
P.5-22
2-High-beam indicator display P.5-20
3-Position lamp indicator display P.5-20
4-Front fog lamp indicator display
P.5-20
5-Multi information screen P.5-9
Interrupt display screen P.5-14
6-Digital speedometer
7-
mark display P.5-15
8-Outside air temperature display
P.5-15
9-Sub unit speedometer P.5-12
10-Cruise control indicator display
P.6-41
11-Energy level gauge P.5-8
12-Parking brake indicator display P.5-21
13-Brake auto hold standby indicator dis-
play (white) P.6-28
Brake auto hold indicator display (green)
P.6-28
14-READY indicator P.5-21
15-Drive mode indicator P.6-26
16-Energy usage indicator P.5-8
17-Select position indicator P.6-20
18-Odometer P.5-15
19-Seat belt warning display P.4-13
20-Door-ajar warning display P.5-21
21-Oil pressure warning display P.5-21
To Next Page
