Using the result of a single measurement, you can make calculations or
analyze assessment profiles under two different assessment conditions
(standard, profile, filter, etc.) without using the recalculation feature.
The stylus alarm function cumulates the measured lengths, and displays
the message when designated threshold value exceeds the cumulative
distance.
You can make a maximum of 300 statistical measurements using up to
three parameters to obtain averages, standard deviations, maximums,
minimums, passing rates, and histograms (upper and lower limits can be
displayed). This feature is ideal for day-to-day data management.
1-parameter display:
one parameter measurement result
Profile display: one parameter measurement
result and the measured profile
4-parameter display: four parameter
measurement results
Trace display: the ten latest measurement results
using the same parameter
After completing measurement, you can modify the assessment conditions (standard, profile, and parameter) and easily recalculate the results using the
new condition.* *Not possible with all measurement conditions.
Recalculation function
Positive stylus contact indication
Dual assessment of a single measurement
Stylus alarm function
Extensive statistical processing features
Measurement results can be displayed in several ways
No contact Contact
Stylus contact with the workpiece is indicated by color coding in the
display. This is helpful when visibility of the surface to be measured is
restricted (e.g. when measuring within a shrouded feature or groove).
Measurement results can be presented in the form of a 1-parameter, profile, 4-parameter or trace display.
