6
UNBOXING THE SLATE (Slate tables only:)
AFTER CRATE PARTS ARE REMOVED, BEND NAILS OR STAPLES OVER WITH A HAMMER
AT ONCE! USE CAUTION WHEN HANDLING CRATE PARTS!
14. It is now time to uncrate the slate pieces.
With a claw hammer or crow bar, pry off
crate top at the notched corner. (See
figure 8) BE CAREFUL NOT TO
DAMAGE SLATE INSIDE! SLATE IS
BRITTLE AND CAN BE EASILY
DAMAGED IF HIT OR PRIED AGAINST!
15. Remove the front rail of the crate. Slide the
slate out the front of the crate. (Figure 9)
Figure 9
Figure 8
UNBOXING THE SLATRON (Slatron tables only)
16. It is now time to unbox the slatron
pieces. BE CAREFUL NOT TO DAM-
AGE SLATRON INSIDE! SLATRON
CAN BE EASILY DAMAGED IF HIT
OR PRIED AGAINST! (See Figure
10)
If the edges of your Slatron has
"fuzz" on it, lightly sand to remove
with sandpaper provided in kit No.
5A-6191-00.
Figure 10
The sheets of slatron may not be completely flat when
removed from the shipping carton. This is normal. Once
they have been placed on the table frame and securely
fastened down, they will become straight and flat.
IMPORTANT!
To Next Page
