ML30, ML40 Setting up and connecting the refrigerator
13
➤ Relocate the bottom right hinge to the top left in the refrigerator door.
➤ Relocate the top right hinge to the bottom left in the refrigerator door.
➤ Insert the hinges into the hinge holes on the housing.
➤ Reattach the hinges and the cover caps with the eight bolts.
➤ Check that the door is easy to open and close and whether it closes her-
metically.
6.3 Changing the decorative plate
You can change the decorative plate on your refrigerator to improve the
appearance.
This is how to change the decorative plate (see fig. 8, page 5):
➤ Remove the two bolts on the top hinge.
➤ Remove the refrigerator door by lifting the door off the lower hinge.
➤ Remove the three bolts on the bottom of the refrigerator door.
➤ Remove the lower frame and pull out the decorative panel.
I
➤ Slide the new decorative plate into the frame of the refrigerator door.
➤ Mount the lower frame and put the refrigerator door back on again.
6.4 Mounting the drag hinge
I
You can mount a drag hinge that allows the refrigerator door to be opened at
the same time as the door of the built-in cabinet.
➤ Install the drag hinge as illustrated in fig. a, page 6.
NOTE
The new decorative plate can be mounted more easily if the upper
corners are cut off by 5 x 5 mm.
NOTE
Note the distances to the built-in cabinet in fig. 9, page 6 and
fig. 0, page 6.
